SpeedCouple pre-installed swivel coupling connects faster and cuts material costs by as much as 50%, compared with standard couplings. Just turn SpeedCouple, not the conduit. It’s available on rigid metal conduit (RMC) and intermediate metal conduit (IMC).
RMC
Trade sizes: 2−6
Lengths: 10′
Compliance: UL-6, UL-514B, ANSI C80.1, NEC Article 344, and WW-C-581. All Western products are cULus listed.
IMC
Trade sizes: 2−4
Lengths: 10′
Compliance: UL-1242, UL-514B, ANSI C80.6, NEC Article 342, WW-C-581
Standard couplings
80 seconds per connection
$22.21 per 100 ft. (based on $100/hr. labor rate)
SpeedCouple
10 seconds per connection
$2.67 per 100 ft.
SpeedCouple saves $19.54 per 100 ft.!
Jay Burris, Manager of Codes and Standards, provides an overview of Western Tube’s SpeedCouple as well as recommended installation instructions.
Watch the video
